A general contractor in New York was renovating a commercial building. The project required cutting large openings in reinforced concrete walls for elevators, windows, and doors. Traditional chipping methods would damage the structure and create excessive noise and dust.
The contractor selected our wall saw cutter – specifically the YG-600TM hydraulic model. YG machine arrived on-site in early 2026 and has been operating for over 3 months. The machine has completed more than 200 meters of cutting with precise, damage-free results.
Technical Specifications of the Hydraulic Concrete Wall Saw
The following parameters define the hydraulic concrete wall saw delivered to the United States:
| Parameter | Value |
| Model | YG-600TM |
| Max. power | 25 KW |
| Motor cooling method | Air cooling |
| Rated voltage | 380V 50HZ 3 phase (customizable) |
| Pressure stages | 3 |
| Max. operating pressure | 200 bar / 20 Mpa |
| Oil flow rate | 30-80 L/min |
| Dimensions | 650 mm × 600 mm × 1150 mm |
| Weight | 180 kg |
Saw blade options for this wall saw cutter:
| Saw blade diameter | Max. cutting depth |
| 800 mm | 30 cm |
| 1000 mm | 40 cm |
| 1200 mm | 50 cm |
| 1400 mm | 60 cm |
| 1600 mm | 70 cm |
Standard configuration of the machine includes: pump station, wall saw head, 1 m guide rail × 1, 2 m guide rail × 1, 10 m oil hose × 6, 850 mm blade guard × 1, 800 mm blade × 1, rail mounting bracket × 4, rail stop × 4, and tool box × 1.
Receive Detailed Parameter List
Site Challenges for the Wall Cutting Saw Machine
The New York project presented several challenges for any machine:
- Reinforced concrete walls – 50 cm thick with dense rebar
- Structural integrity – openings had to be cut without cracking the surrounding wall
- Noise and dust limits – the building remained partially occupied
- Limited access – narrow corridors restricted large equipment
Manual breaking would have caused structural damage and project delays. The contractor needed a wall saw cutter that could deliver clean, precise cuts with minimal vibration.
Installation and Setup of the Hydraulic Concrete Wall Saw
The hydraulic concrete wall saw was assembled on-site within one day. The guide rails were fixed to the wall using mounting brackets. The saw head was then mounted on the rails, and the oil hoses were connected to the pump station.
Key setup steps for the machine:
- Rail alignment and locking
- Saw head positioning
- Water supply connection for blade cooling
- Voltage check (380V 50Hz 3 phase, customized for US site)
The machine required only one operator for installation and cutting. The modular design allowed quick repositioning between openings.
Get Professional Selection Advice
Operational Performance of the Wall Saw Cutter
Over three months of operation, the wall saw cutter delivered consistent performance. The machine used a 1200 mm blade to achieve a 50 cm cutting depth.
Performance data:
- Cutting speed: 2-3 m/h in reinforced concrete
- Daily output: 16-24 m (8-hour shift)
- Blade life: approximately 100 m or 15-20 m² per blade
- Cut quality: smooth, flat surface with no structural damage
- Water cooling: continuous supply to the saw head
The machine completed 200 meters of cutting in 12 working days. No structural cracks were observed in the walls after cutting.
Why YG Wall Cutting Saw Machine Suits US Conditions
The machine offers several advantages for US construction projects:
- Structural safety – The machine cuts without impact, avoiding damage to the building structure. This is critical for renovations and reinforcements.
- High efficiency – The 25 KW motor delivers fast cutting speeds. The wall saw cutter completes openings in hours, not days.
- Clean operation – Water cooling suppresses dust. The machine produces low noise, suitable for occupied buildings.
- Flexible voltage – The standard 380V 50Hz 3-phase can be customized for US power requirements.
- Portable design – At 180 kg, the machine is easy to transport and set up in tight spaces.
Find The Right Solution For Your Job
Maintenance and Durability of the Hydraulic Concrete Wall Saw
The machine requires simple routine maintenance:
- Daily: Check oil hoses, blade wear, and water supply
- Weekly: Grease guide rails and inspect hydraulic connections
- Monthly: Check hydraulic oil level and filter condition
- Blade: Replace when cutting speed drops significantly
The machine is built with durable components. The air-cooled motor and robust pump station ensure long service life. The machine showed no major wear after 3 months of daily use.
Applications and Certification of the Wall Saw Cutter
The wall saw cutter is suitable for:
- Reinforced concrete walls, brick walls, and stone
- Cutting door openings, window openings, and elevator shafts
- Building renovation, reinforcement, and design changes
- Large-area wall cutting with structural integrity
The machine shipped to the US includes a complete operation manual. The voltage was customized to meet local requirements. The machine complies with standard construction equipment safety practices.
Get Your Project‑Specific Quote
Wall Cutting Saw Machine Delivers Results in the US
The machine completed the New York renovation project. Key outcomes after 3 months:
- Model: YG-600TM machine
- Application: Cutting 50 cm reinforced concrete walls
- Total cutting length: 200 meters
- Cutting speed: 2-3 m/h in concrete
- Blade life: 100 meters per blade
- Downtime: Zero unscheduled stops
- Structural damage: None
For US contractors needing precise, safe concrete cutting, YG wall saw cutter – and the machine range – offers a reliable solution. The machine is a practical choice for modern renovation and construction.
