Many overseas contractors and demolition crews struggle to pick the right wall cutting saw machine. The wrong model causes slow cutting, rapid blade wear, and expensive downtime. This buying guide covers all key selection factors, working condition matching, and model recommendations.
Get Professional Selection Advice
Key Technical Specifications – At a Glance
Hydraulic Wall Saw
| Model | YG-600TM | YG-700TM | YG-800TM |
| Max.power | 25KW | 30KW | 32KW |
| Motor cooling method | Air cooling | water cooling | water cooling |
| Rated voltage | 380V 50HZ 3phase | 380V 50HZ 3phase | 380V 50HZ 3phase |
| Pressure stages | 3 | 3 | 3 |
| Max. operating pressure | 200bar/20Mpa | 210bar/21Mpa | 210bar/210Mpa |
| Oil flow rate | 30-80L/min | 30-100L/min | 40-100L/min |
| Dimensions | 650mm*600mm*1150mm | 500mm*520mm*1100mm | 680mm*550mm*700mm |
| Weight | 180kg | 118kg | 120kg |
High-Frequency Wall Saw
| Saw Blade | |
| Max. cutting depth | 510mm |
| Max. saw blade | φ1200mm |
| Saw blade fixing(flush cuts) | 6 countersunk head screws,110mm graduated circle. |
| Electric motor(water cooling & high frequency) | |
| Max. Output Power | 16kw |
| IP Classification | IP 67 |
| Weight | |
| Wall Saw 105DM Incl. Feed Electric Motor | 27kg |
| Electric Main Motor 16kw | 18kg |
| Control Unit | |
| Voltage | 380-460V(single phase available) |
| Frequency | 50Hz/60Hz |
| Weight | 19kg |
| Wireless Control | 2kg |
Electric Wall Saw
| Electric Type | |||
| Model | YG-800 | YG-1000 | YG-1200 |
| Type | Manual type / Semi-automatic type / Full automatic type (every model has three types) | ||
| Cutting depth | 320mm | 420mm | 520mm |
| Saw blade diameter | 800mm | 1000mm | 1200mm |
| Power/Voltage | 7280w/220v | 7580w/220v | 7880w/220v |
| Rotary speed | 400r/min | 380r/min | 350r/min |
| Machine weight | 35kg | 38kg | 45kg |
| Machine size | 55*55*78cm | 55*55*88cm | 55*55*98cm |
Type options: Manual, semi-automatic, full automatic (every model has three types).
Receive Detailed Parameter List
Hydraulic Wall Saw Selection Step 1
Before you pick any wall cutting saw machine, check your site and cutting conditions first. This saves you from costly mistakes.
① Material to cut – Is it reinforced concrete, brick wall, or stone? The machine handles all of these. Harder materials need higher power and water cooling.
② Cutting depth/wall thickness – This is the most important question. Hydraulic models cut up to 73cm. High-frequency models cut up to 51cm. Electric models cut 30- 50 cm. Choose based on your maximum depth.
③ Power source available – Wall cutting saw machine uses 380V 50Hz 3-phase (can be customized). High-frequency wall saw switches freely between 380V and 220V. The electric wall saw uses 220V only and cannot be changed.
④ Cutting application – Door openings, windows, elevator holes, or large wall sections? The machine is designed for flat surfaces with guide rails. For irregular objects or depths over 73cm, a wire saw is recommended.
⑤ Special local conditions – High temperatures, limited water supply, or remote sites? Tell your supplier.
Get Professional Selection Advice
Match Hydraulic Concrete Wall Saw With Global Working Scenarios
1. European Building Renovation – Door and Window Openings
Scene: Old building renovation in city centers. Cutting door openings, windows, and elevator holes in reinforced concrete walls.
Pain point of old solution: Traditional hammering damages the building structure. Dust and noise disturb neighbors. Manual cutting is too slow.
Recommended model & benefits: Wall cutting saw machine YG-600TM – 25KW, max cutting depth 62cm. Structure-safe cutting with no vibration damage. Clean openings in one pass. Water cooling controls dust.
2. Middle East Concrete Wall Cutting – High Temperature
Scene: Cutting thick concrete walls in hot climates. High temperatures, dusty conditions.
Pain point of old solution: Air-cooled motors overheat quickly. Standard saws lose power in high heat.
Recommended model & benefits: Hydraulic concrete wall saw YG-700TM or YG-800TM – 30-32KW, water-cooled. Water cooling prevents overheating. 73cm max depth handles thick walls.
3. North American Bridge and Infrastructure Cutting
Scene: Cutting concrete bridge sections and infrastructure elements. Heavy reinforced concrete.
Pain point of old solution: Breaker hammers are too slow. Wire saws need more setup time for small cuts.
Recommended model & benefits: Wall cutting saw machine YG-800TM – 32KW, 73cm cutting depth. Fast setup with guide rails. Cuts reinforced concrete efficiently.
4. Latin American Building Demolition – Large Wall Sections
Scene: Removing large concrete wall sections in building demolition. Need for deep cuts and fast progress.
Pain point of old solution: Multiple tools needed for different tasks. Slow cutting delays the project.
Recommended model & benefits: Hydraulic wall saw YG-800TM – 32KW, 73cm depth. Cuts large sections in fewer passes. Guide rails can be connected for longer cuts.
Share Your Site Conditions With Us
Common Buying Mistakes for Wall Cutting Saw Machine Buyers
Mistake 1: Choosing the wrong model without confirming cutting depth
Cutting depth is the most critical factor. Hydraulic models cut 62- 73 cm. Electric models cut only 30- 50 cm. Correct approach: Measure your wall thickness first. For depths over 73cm, use a wire saw instead.
Mistake 2: Ignore voltage requirements
A wall cutting saw machine needs 380V 3-phase. An electric wall saw needs 220V and cannot be changed. High-frequency switching between 380V and 220V. Correct approach: Confirm your site voltage before ordering.
Mistake 3: Forget to match saw blade with cutting depth
Blade size determines cutting depth. 800mm blade = 30cm. 1200mm blade = 50cm. 1600mm blade = 70cm. Correct approach: Order the correct blade size for your depth requirement.
Mistake 4: Neglect water cooling
Cutting generates high heat. Water cooling is required. Correct approach: Prepare a water supply and connect it to the machine head inlet.
Mistake 5: Use wall saw on irregular objects
The wall saw machine needs a flat surface for guide rail mounting. Irregular stones or objects need a wire saw. Correct approach: Confirm your material surface is flat before choosing a wall saw.
Mistake 6: Forget about blade consumption
Blades are consumables. One blade lasts about 15-20 square meters or 100 meters. Correct approach: Order spare blades with your initial purchase.
Find The Right Solution For Your Job
Send Your Project Details to Our Engineer
Tell us: material to cut (concrete, brick, or stone), cutting depth/wall thickness, power source available (voltage), working country, and site conditions. Our engineer will recommend the most suitable wall cutting saw machine model for you.
