Choosing an excavator ripper for sale starts with the carrier excavator. Different excavator sizes require different ripper dimensions and weights, so match the model to the excavator tonnage first.
I Need a Ripper for a Mini Excavator
For smaller excavators, a compact ripper attachment helps keep the attachment weight and overall size within the carrier’s working range.
The YG-00 is designed for 1–2 ton carriers and weighs only 30 kg. The YG-01 fits 3–4-ton excavators and weighs 40 kg. For 4–6-ton excavators, the YG-02 weighs 80 kg.
| Model | Carrier | Weight | Length | Width |
| YG-00 | 1–2 T | 30 kg | 523 mm | 130 mm |
| YG-01 | 3–4 T | 40 kg | 523 mm | 130 mm |
| YG-02 | 4–6 T | 80 kg | 656 mm | 180 mm |
Get Professional Selection Advice
I Need a Hydraulic Ripper for Excavator with a Mid-Size Carrier
When the excavator becomes larger, attachment dimensions and weight increase accordingly. An excavator ripper for sale should be selected according to the carrier range rather than by attachment size alone.
The YG-04 is suitable for 6–9 ton excavators, while the YG-06 fits 12–16 ton carriers. The YG-08 and YG-08S are designed for 20–23 ton and 23–26 ton excavators, respectively.
This range allows the ripper size to match the excavator more closely.
I Need a Larger Ripper for Heavy Excavators
For larger carriers, the excavator ripper needs to match a higher excavator weight class.
| Model | Carrier | Weight | Length | Width |
| YG-10 | 26–30 T | 600 kg | 1290 mm | 400 mm |
| YG-14 | 30–40 T | 760 kg | 1290 mm | 400 mm |
| YG-17 | 40–52 T | 1030 kg | 1500 mm | 465 mm |
| YG-20 | 50–90 T | 1200 kg | 1550 mm | 465 mm |
For projects using 30-ton or larger excavators, these models provide different size options according to the carrier class.
Find The Right Solution For Your Job
I Need a Root Ripper for Mini Excavator with the Right Dimensions
When comparing an excavator ripper for sale, attachment dimensions are also important. Length, width, and thickness change between models.
The smallest models have a thickness of 36 mm, while larger models reach 110 mm. This makes dimensional matching useful when checking whether the attachment fits the intended excavator and working setup.
Get Your Project‑Specific Quote
Still Not Sure Which Excavator Ripper Fits the Project?
Start with these four specifications:
| Selection Point | What to Check |
| Excavator size | Match the carrier tonnage |
| Attachment weight | Check whether the excavator can handle the model |
| Length and width | Match the available working space |
| Thickness | Compare the required attachment size |
For example, a 3–4 ton excavator can be matched with YG-01, while a 20–23 ton carrier can use YG-08. For larger carriers, YG-17 and YG-20 cover 40–52 ton and 50–90 ton excavator classes respectively.
Selecting an excavator ripper for sale by excavator tonnage first makes model comparison faster and reduces the risk of choosing an attachment that is too large or too small for the carrier.
