Hydraulic diamond wire saw machine is a cutting tool that uses a wire loop with diamond segments to cut hard materials. A hydraulic motor drives the wire at adjustable speeds. YG machine runs at three output shaft speeds: 350, 940, and 1300 r/min. The maximum wire length is 20 meters.
A gear pump powers the hydraulic machine in this article. The pump delivers 40-100 L/min of hydraulic flow at 15-20 MPa working pressure. The feeding method is fully hydraulic – the operator does not push the wheel manually. The hydraulic system controls everything.
Hydraulic Diamond Wire Saw Machine – Complete Parameter Table
Below are the complete specifications for our machine. All data are based on factory testing.
Wire Saw Wheel Parameters
| Parameter | Value |
| Wire Drive Mode | Hydraulic |
| Motor Type | HM-80, 2 Cylinders |
| Minimum Input Power | 25HP / 33HP |
| Output Shaft Speed | 350 / 940 / 1300 r/min |
| Maximum Wire Length | 20m |
| Feeding Method | Fully Hydraulic |
| Wire Saw Wheel Weight | 64 kg |
| Motor Weight | 14 kg |
Hydraulic Pump Parameters
| Parameter | Value |
| Motor Power | 22 / 25 kW |
| Voltage | 220V / 380V, 50Hz |
| Hydraulic Pump Type | Gear Pump |
| Main Drive Motor | 40-100 L/min |
| Working Pressure | 15-20 MPa |
| Oil Tank Capacity | 17 L |
| Weight | 160 kg |
| Size | 700×700×1200 mm |
| Size | 1700×700×800 mm |
The wheel unit weighs 64 kg, plus a 14 kg motor. The hydraulic pump unit weighs 160 kg and holds 17 L of oil.
Receive Detailed Parameter List
Concrete Rope Saw – Wire Saw Wheel Specifications
The concrete rope saw wheel is the part that holds and drives the diamond wire. Here is what the wheel unit includes.
Motor type: HM-80, 2 cylinders. This hydraulic motor drives the wheel at the selected speed.
- Minimum input power: 25HP or 33HP. Make sure your power source meets this requirement.
- Output shaft speed: 350 / 940 / 1300 r/min. Three speeds are available for different cutting conditions.
- Maximum wire length: 20 meters. This is the longest wire loop the unit can drive.
- Weight: The wheel itself weighs 64 kg. The motor adds 14 kg.
- Wire drive mode: Hydraulic. No electric motor on the wheel – all power comes from the hydraulic pump.
YG hydraulic diamond wire saw machine setup keeps the wheel unit light and compact. The heavy hydraulic pump stays on the ground or on a separate cart. The wheel can be mounted on a frame or track for guided cutting.
Hydraulic Wire Saw – Hydraulic Pump Specifications
The machine pump unit supplies pressure and flow to the wheel motor. Here are the full pump specifications.
- Motor power: 22 kW or 25 kW. Two power options are available. Choose based on your cutting demand.
- Voltage: 220V or 380V, 50Hz. Make sure your site power matches this.
- Hydraulic pump type: Gear pump. Simple, reliable, and easy to maintain.
- Main drive motor flow: 40-100 L/min. This is the oil flow the pump delivers to the wheel motor.
- Working pressure: 15-20 MPa. The system operates within this pressure range.
- Oil tank capacity: 17 liters. This is the hydraulic oil reservoir size.
- Weight: 160 kg for the pump unit.
- Size: Two dimensions are listed in the document – 700×700×1200 mm and 1700×700×800 mm.
The machine pump runs on 220V or 380V mains power. It drives the wheel motor through hydraulic hoses. The wheel and pump are separate units connected by hoses. This gives flexibility in where you place each part on site.
Find The Right Solution For Your Job
Key Features of YG Hydraulic Diamond Wire Saw Machine
Here are the main features of this hydraulic diamond wire saw machine based on its specifications.
- Fully hydraulic feeding – The feed system uses hydraulic force, not manual turning. This gives consistent cutting pressure and reduces operator fatigue.
- Three-speed output shaft – 350 / 940 / 1300 r/min. You can select the best speed for the material and wire type.
- 20-meter maximum wire length – Long enough to cut large sections without repositioning the machine.
- Gear pump design – Simple, robust, and low maintenance. Gear pumps are known for reliability in construction environments.
- 22/25 kW motor options – Two power levels let you match the machine to your job size and available power supply.
- Compact wheel unit – The wheel weighs only 64 kg, plus 14 kg for the motor. Easy to move and mount on different frames.
- Separate pump unit – The 160 kg pump stays on the ground. Only the light wheel unit needs to be positioned at the cut.
Diamond Wire Saw Machine – Why Choose Hydraulic Drive?
A hydraulic diamond wire saw machine with hydraulic drive offers several advantages over electric models.
- Light wheel, heavy pump – The hydraulic design separates the power source from the cutting head. The wheel unit stays light and easy to handle. The pump unit stays on the ground.
- Smooth speed control – Hydraulic motors deliver smooth torque at all three speeds. There is no electric motor on the wheel to burn out or overload.
- Flexible setup – The pump connects to the wheel with hydraulic hoses. You can place the pump away from the cutting area – useful in confined spaces.
- Simple maintenance – Gear pumps are easy to service. The oil tank holds 17 L, so oil changes are straightforward.
- Works with standard power – The pump runs on 220V or 380V, 50Hz power. Most job sites have one of these available.
For contractors who cut concrete regularly, this machine offers a practical balance of power, weight, and portability.
Get Professional Selection Advice
Concrete Rope Saw – Setup and Operation
Setting up this machine involves a few basic steps.
Step 1 – Position the pump unit. Place the 160 kg hydraulic pump near a power source. Connect the 220V or 380V supply.
Step 2 – Mount the wire wheel. Attach the 64 kg wheel unit to your cutting frame or track. Connect the hydraulic hoses to the pump.
Step 3 – Install the diamond wire. Loop the wire around the wheel and through the material to be cut. Maximum wire length is 20 meters.
Step 4 – Select the speed. Choose 350, 940, or 1300 r/min based on the material and wire type. Start at a lower speed for initial cuts.
Step 5 – Start the pump. Turn on the hydraulic pump. Check that working pressure stays between 15-20 MPa. Adjust flow if needed.
Step 6 – Begin cutting. The fully hydraulic feeding system moves the wheel into the cut. Monitor the pressure and speed throughout the operation.
Because the feeding is fully hydraulic, the operator does not need to stand close to the cutting point. This improves safety and reduces physical effort.
Get Your Project‑Specific Quote
Get Your Hydraulic Wire Saw Quote Today
Ready to add a hydraulic wire saw to your equipment fleet? Send us your cutting requirements – material type, maximum cut depth, and available power supply. We will reply within 24 hours with the right hydraulic diamond wire saw machine configuration and price.
Phone / WhatsApp / WeChat: +86 159 3715 3321
